Leaded Chip Attenuators



Reurn List   I want to customize

Can't meet the demand with existing products?

Scroll to the right to view the specifications

额定功率

衰减值

频率

最大驻波

尺寸(mm)

产品型号

Power Rating

Attenuation

Frequency

(Max)

Dimensions

Model

(W)

Value(dB)

(GHz)

VSWR

W

L

T

H

I

Tw

Click below to view specifications

10


20

6

1.25

4

4

1

N/A

N/A

N/A

RFR20-10A0702A

60


30 2.5 1.15 6 5 1 N/A
N/A
N/A

50


6
3 1.2 6 6 1 1.9 6 1 RFR6-50A1101A

100


30 2.7 1.15 8.9 5 1 N/A
N/A
N/A
RFR30N-100A46301B

100


20 3 1.2
8.9
5.4
1 N/A
6 1 RFR20N-100A4502C

150


30 3 1.2 9.5 6.35 1 N/A
N/A
N/A
RFR50N-150A2356C

1000


23 2.2 1.2 12.7 12.7 1.4 N/A
8 0.8 RFR30N-250A2402C




Suggested mounting procedures:

1. Solder part or tabs in place with controlled  temperature iron (260℃).

2.Forming a small loop in the tab will act as a strain relief as the heat is dissipated.
